Digital Flame Control
Double-Walled Roasting Drum
Drum Speed Control
Exhaust Fan Speed Control
| SPECIFICATION | VALUE |
|---|---|
| Model | OKS-15 |
| Drum Capacity | 15 kg. |
| Drum Construction | Double - Walled |
| Roasting Time | 10 - 20 minute |
| Gas Types | LPG - PROPANE or NATURAL GAS |
| Burner Control | Digital |
| Heating System | Thermal Transfer |
| Hourly Roast Output (Approximately) | 60 kg. |
| Drum Speed Control | Optional |
| Drum Fan Speed Control | Optional |
| Voltage | 220 - 380 V |
| Frequency (Hz) | 50 - 60 Hz |
| Phase | 1 - 3 Phase |
| Total Motor Power | 1,1 KW |
| Dimensions (LxWxH) | 142 x 240 x 225 cm / 56 x 95 x 88 inch |
| Weight | 800 kg. |
| Number of Motors | 4 pcs |
Other Specifications
- Double walled roasting drum.
- Digital flame control
- Time display
- USB computer connection for bean and
- exhaust temperature
- Sight glass , sampling tube and digital temperature
- makes easy coffee roasting process.
- Independent motors for the roasting drum and
- cooling tank.
- Independent fans for the roasting drum and
- cooling tank.
- A large cooler with fan guickly cools the coffee.
- An external chaff collector is included with roaster.
- Low noise level.
- Easy to use. High quality.
Gas Security System
To shot down all system in conditiion of any abnormality in gas preassure.
Emergency Button
To turn off all roasting process.
Optional Specifications
- Drum & Drum fan speed control.
- PLC control sytem
- Optional embossed logo on body trim.
- Optional copper and stainless steel available
- on drum and cooling tank.
- Destoner
- Afterburner
